ROHM Semiconductor EMARMOUR™ AEC-Q100 CMOS Op Amps

ROHM Semiconductor EMARMOUR™ AEC-Q100 CMOS Op Amps are input/output rail-to-rail CMOS operational amplifiers with an operating voltage range of 4V to 14V. These devices leverage proprietary technologies covering layout, processes, and circuit design to achieve ultra-high noise immunity that minimizes output voltage fluctuation across the entire noise frequency band during noise evaluation testing under the international ISO 11452-2 standard. This unprecedented noise immunity reduces design load and improves reliability by solving noise-related issues in the development of various systems.

The ROHM Semiconductor EMARMOUR™ Op Amps are available in a compact SSOP-5 package and are AEC-Q100 qualified for automotive applications. With a high slew rate, low input bias current, and high open-loop voltage gain, the EMARMOUR Op Amps are ideal for automotive requirements such as sensor amplifiers, engine control units, electric power steering, and anti-lock braking systems.

Features

EMARMOUR series
AEC-Q100 qualified (Grade 1)
Industry-leading noise immunity significantly reduces the design load for countermeasures
Significantly improves noise immunity by conducting a thorough review of circuits, layout, element size, and other factors
Significantly reduces the time, effort, and costs of noise countermeasures
Provides superior versatility and complies with international standards for reliability
Input/output rail-to-rail

Wide operating supply voltage ranges
- Single supply: 4.0V to 14.0V
- Dual supply: ±2.0V to ±7.0V
Low 2.3mA to 5mA supply current range
3.5mA or 6mA output current per channel
High 110dB open-loop voltage gain
3.5V/µs slew rate
1.0mV input offset voltage
1pA input bias current
-40°C to +125°C operating temperature range
MSOP-8 or SSOP5 package options
